■ 产品概述

      V型球阀采用金属硬密封结构，V型阀芯及金属阀座在回转过程中，球芯的V型缺口与阀座做比例流量调节，并且密封面紧密配合，V型口具有强

大切断介质、杂质的功能，避免阀门卡死现象发生，并具有自洁功能；配合气动执行器，可以实现90°范围的启闭，跟定位器配套实用可实现远程

微电脑控制阀门流量开度，可实现比例调节：与二位五通电磁及控制箱配套实用，可实现开关控制。

■ 适用介质：

        适用于含纤维、固体颗粒、浆料等介质。因些可广泛用于造纸、石油、化工、化纤、电力、冶金、制药及环保等行业。

        口径：DN25~DN250/1-10"(对夹)、DN25~DN600/1-24"(法兰)

        压力等级：DN10/16/25/40/65、ANSI   150LB/300LB

■ PRODUCT INTRODUCTION

    V type ball valve use hard seal material structure, V-type valve core and metal seat in the rotation process, the V-notch ball core and valve

seat proportional flow control, and and sealing surface work closely,V-type has a powerful cut off the medium, impurities function to avoid the the

valve stuck phenomenon, and has a self-cleaning function; with pneumatic actuators can achieve the range of 90 ° to open and close, with the

locator supporting the use of remote microcomputer to control the degree of opening of the valve flow ratio adjustment;supporting the use of two

five-way solenoid control box, switch control.

■ APPLICATION MEDIUM

         Suitable for containing fiber, solid particles, slurry and other media, it can be widely used for paper, petroleum, chemical industry, chemical

fiber, electricity, metallurgy, pharmaceutical and environmental industries.Nominal Through Diameter: DN 25 ~DN250 / 1-10"£Lug/ Clip-on )

DN25 ~ DNV600/ 1-24"Nominal Pressure: DN 10/DN16/DN25/DN40/DN65  ANSI 150LB/300LB
